Vaisala DRYCAP DMT143 - Figure 13 DSC74 B

DSC74B parts are:
• Sampling cell, thread G3/8"
• Connection part with a needle valve and an integrated leak screw
• Reducing Nipple (thread adapter), G3/8" - G1/2"
• Reducing Adapter (thread adapter), G3/8" - G1/4"
1
2
Figure 13 DSC74B
1
Gas goes in
2 Gas comes out
Chapter 4 – Installation
31
