Figure 16 Alternative Assembly of DSC74C (for Tight Spaces)
1
Gas comes out
2 Coil
3 Thread, max. size 7 mm
4 Gas goes in
5 Valve
The thread size cannot exceed 7 mm. Use the provided adapter to avoid damage to the
transmitter.
