7.3 Calibration and Adjustment with Insight PC
Software
Figure 26 Insight Calibration View
You can use the Insight PC software to calibrate and adjust the RH or T measurement in 1 or 2
points. Either a reference environment (such as a humidity calibrator) or a reference
instrument (for example, a second HMD60 transmitter) can be used when adjusting.
When you use the Insight PC software to adjust the measurement
or to restore the factory settings, always return the physical adjustment
trimmer(s) on the transmitter component board to the middle position before
starting. When you make an adjustment with Insight, the position in which the
adjustment trimmer is at that point is set as the ±0 point.
CAUTION!
More Information
‣
Connecting to Insight Software (page 18)
Chapter 7 – Calibration and Adjustment
37
