Table 3 HMD65 Measurement Parameters and Default Scaling
Parameter Default Scaling for 1 … 10 V Output Range
Relative humidity (RH) 0 … 100 %RH
Temperature (T) -20 ... +80 °C (-4 ... +176 °F)
Dew point temperature (T
d
) -40 ... +80 °C (-40 ... +176 °F)
Dew point/frost point
temperature (T
df
)
-40 ... +80 °C (-40 ... +176 °F)
Absolute humidity (A)
0 … 300 g/m
3
(0 … 131.1 gr/ft
3
)
Mixing ratio (X) 0 … 600 g/kg (0 … 4200 gr/lb)
Wet-bulb temperature (T
w
) -40 ... +80 °C (-40 ... +176 °F)
Enthalpy (H) -40 … 1600 kJ/kg (-9.5 ... 695.6 Btu/lb)
Changing Measurement Parameter Scaling
If your application requires an analog output scaling that diers from the defaults shown in
Table 3 (page 6), you can configure the scaling by connecting the transmitter to Vaisala Insight
PC software (requires Vaisala USB cable 219690).
2.4
Connectivity to Vaisala Insight Software
The transmitter can be connected to Vaisala Insight software using a Vaisala USB cable (order
code 219690). With the Insight software, you can:
• See device information and status.
• See real-time measurement.
• Configure output parameters and scaling.
• Configure serial communication settings.
More Information
‣
Connecting to Insight Software (page 18)
