6. Operating with MI70 Indicator
6.1 Overview of MI70 Support
The MI70 hand-held indicator is a convenient service tool for viewing the measurement
readings and performing calibration and adjustment. MI70 is used as the display and
configuration tool in, for example, the HM70 Hand-Held Humidity and Temperature Meter, and
is also compatible with various Vaisala probes and transmitters.
You can use the MI70 indicator for the following tasks with HMD60:
• Measurement viewing and logging
• Calibration and 1-point adjustment (see Calibration and Adjustment with MI70 Hand-Held
Indicator (page 40))
• Viewing information about the transmitter (serial number, SW version, last adjustment
date)
To connect HMD60 to an MI70 indicator, you need the optional MI70 connection
cable (Vaisala order code 219980SP).
6.1.1 MI70 Indicator Parts
Figure 22 MI70 Indicator Parts
1 Charger socket
2 Function key shortcut buttons . The
functions change according to what
you are doing with the indicator.
3 Arrow buttons:
Move up in a menu
Move down in a menu
Enter a sub-menu
Return to previous menu level
4 Power On/O button
5 Battery compartment at the back of
the indicator
6 Two ports (labeled I and II) for
connecting probes and instruments.
HMD65 User Guide M212243EN-A
30
