5.2. Digital inputs
There are 6 digital inputs available for control purposes. The
polarity – normal open (NO) / normal closed (NC – and a delay
can be configured according the application. The signals are
available for the output matrix, block matrix, user's
programmable logic etc.
The contacts connected to digital inputs DI1 ... DI6 must be dry
(potential free). These inputs use the common internal 48 Vdc
wetting voltage from terminal X3:1, only.
Common
input
Input group
Wetting voltage
On
Off
X7:7
X7: 1-6 (DI 7-12)
≥18 V
DC
or ≥50 V
AC
10 V
DC
or 5 V
AC
NOTE! These digital inputs must not be connected parallel with inputs of an
another device.
Label and description texts can be edited with VAMPSET
according the application. Labels are the short parameter
names used on the local panel and descriptions are the longer
names used by VAMPSET.
Parameters of digital inputs
Parameter
Value
Unit
Description
Set
DI1 ... DI6
0
1
Status of digital input
DI COUNTERS
DI1 ... DI6
0 ... 65535
Cumulative active edge
counter
(Set)
DELAYS FOR DIGITAL INPUTS
DI1 ... DI6
0.00 ... 60.00
s
Definite delay for both on
and off transitions
Set
CONFIGURATION DI1 ... DI6
Inverted
no
yes
For normal open contacts
(NO). Active edge is 01
For normal closed
contacts (NC)
Active edge is 10
Set
Alarm display
no
yes
No pop-up display
Alarm pop-up display is
activated at active DI
edge
Set
On event
On
Off
Active edge event
enabled
Active edge event
disabled
Set
Off event
On
Off
Inactive edge event
enabled
Inactive edge event
disabled
Set
