8.3.2. Rear panel connector X5 (REMOTE)
The X5 remote port communication connector options are
shown in Figure 8.3.2-1. The connector types are listed in Table
8.3.2-1.
Without any internal options, X5 is a TTL port for external
converters. Some external converters (VSE) are attached
directly to the rear panel and X5. Some other types (VEA, VPA)
need various TTL/RS-232 converter cables. The available
accessories are listed in chapter 12 order information.
2&4-wire galvanically isolated RS-485 (Figure 8.3.2-2), Internal
options for fibre optic (Figure 8.3.2-3), and Profibus (Figure
8.3.2-4) are available. See chapter 12 order information.
Table 8.3.2-1 Physical interface and connector types of
remote port X5 with various options. Serial interface (A) is the
default.
Order
Code
Communication interface
Connector type
Pin usage
A
Serial interface for
external converters only
(REMOTE port)
D9S
1 = reserved
2 = TX_out / TTL
3 = RX_in /TTL
4 = RTS out /TTL
7 = GND
9 = +8V out
B
Plastic fibre interface
(REMOTE port)
HFBR-0500
C
Profibus interface
(REMOTE port)
D9S
3=RXD/TXD+/P
4=RTS
5= GND
6=+5V
8= RXD/TXD-/N
D
RS-485, isolated
(REMOTE port)
screw terminal
1= Signal ground
2= Reciever -
3= Reciever +
4= Transmitter -
5= Transmitter +
E
Glass fibre interface
(62.5/125m) (REMOTE
port)
ST
F
Plastic / glass (62.5/125
m) fibre interface
(REMOTE port)
HFBR-
0500/ST
Plastic Rx
Glass Tx
G
Glass (62.5/125m) /
plastic fibre interface
(REMOTE port)
ST/HFBR-
0500
Glass Rx
Plastic Tx
