VAMP 265 - 9.1.3. Digital Inputs; 9.1.4. Trip Contacts; 9.1.5. Alarm Contacts

9.1 Connections
9 Technical data
Technical description
204
VAMP 24h support phone +358 (0)20 753 3264
VM265.EN011
9.1.3. Digital inputs
Number of inputs
6
Operation time
0.00 – 60.00 s (step 0.01 s)
Polarity
NO (normal open) or NC (normal closed)
Inaccuracy:
- Operate time
±1% or ±10 ms
Internal operating voltage
48 V dc
Current drain when active (max.)
Approx. 20 mA
Current drain, average value
< 1 mA
Terminal block:
Max. wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.4. Trip contacts
Number of contacts
2 making contacts
Rated voltage
250 V ac/dc
Continuous carry
5 A
Make and carry, 0.5 s
Make and carry, 3s
30 A
15 A
Breaking capacity, AC
2 000 VA
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
5 A
3 A
1 A
Contact material
AgNi 90/10
Terminal block:
Maximum wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.5. Alarm contacts
Number of contacts
3 change-over contacts (relays A1, A2 and A3)
2 making contacts (relays A4 and A5)
1 change-over contact (IF relay)
Rated voltage
250 V ac/dc
Max. make current, 4s at duty cycle 10%
15 A
Continuous carry
5 A
Breaking capacity, DC (L/R=40ms)
at 48 V dc:
at 110 V dc:
at 220 V dc
1,3 A
0,4 A
0,2 A
Breaking capacity, AC
2 000 VA
Contact material
AgNi 0.15 goldplated
Terminal Block:
Max. wire dimension:
- Phoenix MVSTBW or equivalent
2.5 mm
2
(13-14 AWG)
9.1.6. Local serial communication port
Number of ports
1 on front and 1 on rear panel
Electrical connection
RS 232
Data transfer rate
1200 - 38 400 kb/s
