6.2 Communication protocols
6 Communication
Technical description
146
VAMP 24h support phone +358 (0)20 753 3264
VM265.EN011
The function type and information number used in private
range messages is configurable. This enables flexible
interfacing to different master systems.
For more information on IEC 60870-5-103 in Vamp devices
refer to the “IEC103 Interoperability List” document.
Parameters
Parameter
Value
Unit
Description
Note
Addr
1  254
An unique address within
the system
Set
bit/s
9600
19200
bps
Communication speed
Set
MeasInt
200  10000
ms
Minimum measurement
response interval
Set
SyncRe
Sync
Sync+Proc
Msg
Msg+Proc
ASDU6 response time
mode
Set
Set = An editable parameter (password needed)
Parameters for disturbance record reading
Parameter
Value
Unit
Description
Note
ASDU23
On
Off
Enable record info
message
Set
Smpls/msg
125
Record samples in one
message
Set
Timeout
1010000
s
Record reading timeout
Set
Fault
Fault identifier number
for IEC-103. Starts + trips
of all stages.
TagPos
Position of read pointer
Chn
Active channel
ChnPos
Channel read position
Fault numbering
Faults
Total number of faults
GridFlts
Fault burst identifier
number
Grid
Time window to classify
faults together to the
same burst.
Set
Set = An editable parameter (password needed)
