Engineer programming via the keypad
Installation & Configuration Manual
users to build a set of zones that are identified with a particular area in the building.
The number and type of attributes displayed in the keypad menus for a particular
zone vary depending on the type of zone that is selected. See page.
16.9 Doors
16.9.1 Doors
1. Scroll to DOORS and press SELECT.
2. Scroll to the door to be programmed and press SELECT.
3. Parameters and details, if applicable, are displayed for editing as follows:
- Description
- Door Inputs
- Door Group
- Door Attributes
- Door Timers
- Reader Information (Display only - format of last card used with configured
reader)
Door inputs
Each door has 2 inputs with predefined functionality. These two inputs, the door
position sensor and the door release switch can be configured.
The door position sensor input can be used for the
intrusion part as well. If the door position sensor input is
used also for the intrusion part, the zone number it is
assigned to has to be selected. If the door position
sensor is used only for the access part, the option
“UNASSIGNED” has to be selected.
If the door position sensor is assigned to an intrusion
zone, it can be configured like a normal zone but only
with limited functionality (e.g. not all zone types are
selectable).
If an area or the system is set with the card reader, the
door position sensor input has to be assigned to a zone
number and to the area or the system which have to be
set.
Description of the zone the door position sensor is
assigned to.
Zone type of the zone the door position sensor is
assigned to (not all zones types are available).
The attributes for the zone the door position sensor is
assigned to can be modified.
The area the zone and the card reader are assigned to.
(If the card reader is used for setting & unsetting, this
area will be set / unset).
The resistor used with the door position sensor. Choose
To Next Page
