Engineer programming via the browser
Installation & Configuration Manual
17.9 Configuration
17.9.1 Configuring controller inputs & outputs
17.9.1.1 Editing an input
1. Select Configuration > Hardware > Controller.
The following window will be displayed.
2. Configure the fields as described in the table below.
The number is presented for reference and can not be programmed.
Select the End of Line (EOL) for the zone input (default: 4K7).
Displays if the sensor is an inertia/shock type sensor
Pulse count programmed on the panel that will trigger an alarm from an inertia /
shock sensor.
The Gross attack programmed on the panel that will trigger an alarm from an
inertia/shock sensor
Number of the zone on the panel
Enter a text describing the input (max. 16 characters). This text will also appear
on the browser and keypad.
The type of zone (see page [➙ 347]).
Only if (multiple) Areas is activated in menu Panel Settings > System Settings >
Options. Select the areas to which this zone has been assigned.
An icon in this field indicates that attributes have been programmed for this zone
(see page [➙ 197]).
