Wiring the system

Wiring the zone inputs

Vanderbilt

Installation & Configuration Manual

A6V10276959

01.05.2016

Standard wiring

Normally open terminal

COM

Common terminal connection

Normally closed terminal

10.5 Wiring the zone inputs

The SPC controller has 8 on-board zone inputs. By default these inputs are

monitored using end of line supervision. The installer can choose from any of the

following configurations when wiring the inputs:

 No End of Line (NEOL)

 Single End of Line (SEOL)

 Dual End of Line (DEOL)

 Anti-masking PIR
