Command Profiles
10
1) Max. 400 m between devices / cable types IYSTY 2 x 2 x Ø 0.6 mm (min.), UTP
cat5 (solid core) or Belden 9829.
2) More I/O expanders can be addressed instead of a keypad or door expander,
but number of programmable inputs / outputs cannot exceed specified system
limits.
4.4 SPCP355.300
Number of on-board zones
8
EOL resistor
Dual 4K7 (default), other resistor combinations selectable
Relay Outputs
3 (single-pole changeover, 30 V DC/max. 1 A resistive
switching current)
Electronic Outputs
3 supervised (each max. 400 mA resistive switching current),
Interfaces
X-BUS (in, out, branch)
Mains Voltage
230 V AC, +10 to -15 %, 50 Hz
Operating Current
Max. 245 mA at 12 V DC (all relays activated)
Quiescent Current
Max. 195 mA at 12 VDC
Output voltage
13-14 V DC in normal conditions (mains powered and fully
charged battery),
Auxiliary power (nominal)
Max. 2360 mA at 12 V DC (8 separately fused outputs, max.
300mA per output)
Battery type
 YUASA NP24-12 (12 V 24 Ah)
 Alarmcom AB1227-0 (12 V 27 Ah)
 FIAMM FGV22703 (12V 27Ah)
Battery not supplied
Tamper contact
Front/back tamper switch
Operating temperature
0 to +40 °C
Housing
Metal housing (1.5 mm mild steel)
Colour
RAL 9003 (signal white)
Dimensions
498 x 664 x 157mm
Weight (without batteries)
18.400 kg (housing incl. cover), 11.300 kg (housing without
cover)
IP / IK Rating
30 / 06
