Engineer programming via the keypad
Installation & Configuration Manual
2. Scroll to the desired programming option:
To enable or disable the X-10 functionality on the system.
To add, edit, delete or test X-10 devices.
To enable or disable the X-10 logging.
16.23 Set Date/Time
The date and time can be manually entered on the system. The time and date
information is displayed on the keypad and browser and is used on time-related
programming features.
1. Scroll to SET DATE/TIME and press SELECT.
The date displays on the top line of the display.
2. To enter a new date, press the required numeric keys. To move the cursor to
the left and right, press the left and right arrow keys.
3. Press ENTER to save the new date.
If an attempt is made to save an invalid date value, the text INVALID
VALUE is displayed for 1 second and the user is prompted to enter a valid
date.
4. To enter a new time, press the required numeric keys. To move the cursor to
the left and right, press the left and right arrow keys.
5. Press ENTER to save the new time.
If an attempt is made to save an invalid time value, the text INVALID
VALUE is displayed for 1 second and the user is prompted to enter a valid
time.
16.24 Installer Text
This setting allows the engineer to enter system information and engineer contact
information.
1. Scroll to INSTALLER TEXT and press SELECT.
2. Scroll to the desired programming option:
Used to help identify the system; use a clear and descriptive name for
the installation.
Used to help identify the installation when connected to a central
station (max. 10 digits).
Used for contact purposes.
Used for contact purposes.
Setting to display installer details can during the idle state.
The installer contact details programmed in these menu options should also be
entered on the keypad pull-down label on completion of the installation.
16.25 Door Control
This option allows you to control all the doors of the system.
