Varta element Series - Figure 32: Battery Charger - Rear

140
Subject to modification! Updated 10/2017
Figure 32: Battery charger - rear
1
Connection to the second battery charger
(at expansion stage element 9/12)
2
Inverter connection
 Pull the battery charger out of the compartment using both
hands.
