Preparing the new fan
 Remove and dispose of the plastic housing.
Aid: Size 4 hexagon socket wrench
Figure 39: Removing the plastic housing
 Manually check the fan wheel on a firm fit.
Figure 40: Checking the fan wheel
 Mount the new fan
