Varta element Series - Table 13: Network Parameter Settings

118
Subject to modification! Updated 10/2017
Manual input
 Reactive power function: Select manual input from the
drop-down list.
 You can set the target value for cos(phi) between 0.9
under-excited and 0.9 over-excited. To do so, select the
desired value from the drop-down list.
Target value for cos(phi)
Power factor setting
Under-excited
0.90
-100
0.91
-90
0.92
-80
0.93
-70
0.94
-60
0.95
-50
0.96
-40
0.97
-30
0.98
-20
0.99
-10
1.00
0
Over-excited
0.99
10
0.98
20
0.97
30
0.96
40
0.95
50
0.94
60
0.93
70
0.92
80
0.91
90
0.90
100
Table 13: Network parameter settings
