3. Before Installing the System
34 Green 16/18 Installation Manual
3.3.2 Box No. 2 - Base Unit
Component Size (mm / inch) Weight (kg / lbs.)
Base
1035(L) x 1025(W) x 185(H) /
40.7"(L) x 40.3"(W) x 7.3"(H)
65 / 143
Removing the cover
Open the box cover and remove the packing material, as shown in the figure.
