4. Installing the Equipment: Base Stand (Optional)
Green 16/18 Installation Manual 45
Put the bolts into the holes until
about 30 mm are left
outside.
3. Put the base unit to the column unit by engaging the base holes in the
bolts, as shown in the figure.
Hold the base unit to keep it from falling.
If you do not use the base during the assembly, remove
2 pcs of Truss bolts while installing the front cover as
below.
