4. Installing the Equipment: Base Stand (Optional)
46 Green 16/18 Installation Manual
4. Put the base unit to the column unit by engaging the base holes in the
bolts, as shown in the figure.
Allen Wrench 8 mm / 0.31”
Wrench Bolt
M10 x 25
- 3 pcs
(Part No. 23)
5. Tighten the two wrench bolts.
Allen Wrench 6 mm / 0.24”
