4. Installing the Equipment: Base Stand (Optional)
Green 16/18 Installation Manual 49
Make sure the CEPH cables from the
equipment go through the CEPH armhole.
4. Tighten the three wrench bolts to attach the base unit.
Allen Wrench 6 mm / 0.24”
Wrench Bolt
M8 x 20 - 3 pcs
(Part No. 25)
Flat Washer (Part No. 34)
To Next Page
