4. Installing the Equipment: Base Stand (Optional)
50 Green 16/18 Installation Manual
5. Connect the cables as shown in the figure.
When handling fiber optic cable,
- Do not bend, pull, and/or crush it.
- Ensure that the caps of the fiber optic cable
be removed
- Do not touch the tip of the fiber optic cable to
prevent it from being dirty.
- Insert the fiber optic cable fully until the
click sound is heard.
