3. Before Installing the System
Smart Plus (PHT-35LHS) Installation Manual 39
English
Another location
Items Specification Figure Qty. Comments Location
Confirmed
(OK?)
Base
Front
Cover
N/A
1 N/A
On the
upper side
of the EPS
(Main
Bottom)
Yes □ No □
Column
Back
Cover
N/A
1 N/A
On the
upper side
of the EPS
(Main
Bottom)
Yes □ No □
Wall
Bracket
(For
Wood
Wall)
16 inches
1
For the USA
only
Under the
bottom
side of the
EPS (Main
Left)
Yes □ No □
