3. Before Installing the System
38 Smart Plus (PHT-35LHS) Installation Manual
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
Anchor Bolt
5/16 x 60 w/
Spring and
Flat Washers
10 For Concrete Yes □ No □
35
Wrench Bolt
M8 x 25 w/
Spring and
Flat Washers
2 Yes □ No □
Nut M8
2 Yes □ No □
36
Wall Bracket
Rear
1 Yes □ No □
