3. Before Installing the System
Smart Plus (PHT-35LHS) Installation Manual 37
English
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
28
Flat Head
Screw
M3 x 6 2
CEPH Option
Yes □ No □
CEPH Arm
Cover 4
1 Yes □ No □
29
Flat Head
Screw
M5 x 12 4 Yes □ No □
30 Set Screw M10 x 20 4 Yes □ No □
31
Protractor 1 Yes □ No □
Wall Plate 1 Yes □ No □
Terminal Block
3 Pole
1 Yes □ No □
32
Middle
Bracket
1
Optional
Yes □ No □
Wrench Bolt
M8 x 25 w/
Spring and
Flat Washers
2 Yes □ No □
Nut M8 2 Yes □ No □
33
UP / DOWN
Switch
1
Optional
Yes □ No □
UP / DOWN
Switch Holder
1 Yes □ No □
Double-Sided
Sticker
1 Yes □ No □
Truss Bolt M4 x 10
2 Yes □ No □
34
Wood Screw M8 x 60
8 For Wood Yes □ No □
Spring
Washer
4
Flat Washer 4
Wood Screw M12 x 70 2 For Wood Yes □ No □
