Vatech Smart Plus PHT-35LHS - Page 53

4. Installing the Equipment: Base Stand (Optional)
Smart Plus (PHT-35LHS) Installation Manual 47
English
6. Put the cables inside the CEPH Arm and assemble the CEPH arm cover by
using two flat head screws.
Cross Head
Screwdriver w/
Magnetic Tip
6 mm / 0.24”
Flat Head
Screw
M3 x 6
- 2 pcs
(Part No. 28)
CEPH Arm
Cover 4
(Part No. 28)
