VECTRIX VX-2 SERVICE MANUAL
SECTION E-1:
INDICATION ON SPEEDOMETER DISPLAY & CONTROLLER LED
Indication on LCD Controller
LED
Reason Solution
Accelerator turn
at power up
1 Accelerator is not in
zero position
Release accelerator or turn power
“OFF” and then to “ON” or proceed to
the Accelerator troubleshooting
diagram
Error
Accelerator Volt
2 Accelerator voltage
too high
Release accelerator or turn power
“OFF” and then to “ON” or proceed to
the Accelerator troubleshooting
diagram
Stop scooter
Battery empty!
3 Battery voltage is
under 42V
permanently
Charge the Battery
Error
Overcurrent
4 Controller
defect
Exchange controller and check motor
for short winding against housing
Error
Hall sensor
5 Hall sensor
Malfunction of the
motor
Proceed to Hall Sensor check
Section 4 of Section E
Scooter
Disabled
6 This messages
comes after Stop
scooter
Solve malfunction before this
message
Error
Voltage too high
7 Battery voltage is
over 63V
Use the scooter carefully until
message is over, if not, check if the
real voltage of the battery is lower
than 63V and setting of controller.
Or exchange Controller.
Error
High temperature
9 Temperature of the
controller is >85
o
C
Wait until temperature goes down
under 85
o
C.
Or exchange Controller
Stop scooter
High temperature
10 Temperature of the
controller is >110
o
C
Wait until temperature goes down
under 110
o
C.
Or exchange Controller
Low Battery
Recharge!
11 Battery voltage is
under 42V
> 15 seconds
Charge the Battery
Error
Sidestand out
6 Side stand switch is
active
Check correct function of side stand
switch.
Exchange Side Stand Switch or
controller
System
Error 01
Memory of
speedometer defect
Exchange Speedometer if message is
still there.
The LED on the controller flashes if a malfunction is active.
Example
: LED flash 6 times with 1 Hz, LED off for 2 sec. and starts again.
This means: Disable function active
Version 1.0/May 2011
VECTRIX, LLC
