V-Touch AFAD
MAN-13
User’s Manual
9 Version 2.1
3.1 Activation
You can activate Flagger-Mac units in Solo mode or in Duo Radio mode.
Your unit has been associated with its wireless remote control at the factory. As soon as you activate
the V-Touch in operation mode ( ), the remote control can be used, in solo mode, to operate a
single automated flagger assistance device.
In duo mode, a single operator controls two devices from a single remote.
For more information about the wireless remote control, see section 4.4.1 Wireless Remote Control
.
Before activating your units in Duo Radio mode, you must make sure the two units are equipped with
the Radio option, that this option is activated, and that two units are paired. For more information,
see section 3.4 Pairing the AFAD Units
.
To start signaling operation:
1 Tap Play ( ) and activate the operation mode on the V-Touch AFAD touchscreen controller.
The Activate Flagging Type dialog is displayed.
2 Tap Solo or Duo Radio to choose your operation mode.
Once the activation is done, the wireless remote is operational.
Figure 3-2 Operation mode
The gate closes automatically to safely start operation. Make sure that the Flagger-Mac timing
operates according to your instructions. For more information see section 4.2 Traffic Light and Gate
Timings.
