V-Touch AFAD
MAN-13
User’s Manual
20 Version 2.1
When the unit is connected to JamLogic, an intrusion alarm event is logged.
To turn the alarm off, tap the Options button then Edit Configuration and clear the Use
intrusion check box. Repair the gate and reactivate the alarm.
When the Use manual alarm check box is selected, it makes it possible for a user to setup an
alarm using the wireless remote control.
To activate the manual alarm:
On the remote control simultaneously press and .
The LEDs of all the remote buttons flash twice to confirm. The gates on both Flagger-Mac
units, when paired, are lowered, the red lamps are turned on, and the sound alarms and the
strobe lights on top of the signal heads are activated. The alarm signals go on for 2 minutes
then stop.
You can stop the sequence manually by pressing the same buttons again.
When the unit is connected to JamLogic, a manual alarm event is logged in JamLogic.
4.3 Statuses and Error Messages
When the system encounters a problem, a message appears on the Home screen. The system
statuses are displayed in the section at the bottom right of the screen.
Figure 4-4 Messages and statuses
Tapping the Status section refreshes the status readings.
4.4 Option Screen Overview
This section presents a short description of the function you can access through the Options button.
To open the Options screen, tap Options on the left button menu.
Radio signal,
power, and
remote control
statuses
Error message
Status section
