V-Touch AFAD
MAN-13
User’s Manual
11 Version 2.1
To use the Flagger-Mac in Solo mode, with one flagger per AFAD:
1 Tap Play and select Solo.
The unit gate lowers.
2 Remove the remote control from the container and close the lid.
You do not need to use the V-Touch to operate the gate.
To raise the gate, push the Raise Gate #1 button ( ) on your wireless remote. It rises
immediately and the light turns flashing yellow.
To lower the gate, push the Lower Gate button ( ). The yellow light behaves the same
as a normal traffic light that is flashing, then turns solid before turning red; then the gate
lowers. This, to ensure the greatest possible safety for motorists and flaggers.
If the gate will not open nor close, please refer to the Troubleshooting section of this manual.
3.3 Duo Radio Mode
Duo Radio mode can be activated only on automated flagger assistance devices (AFAD) that are
equipped with the Radio option.
This mode allows one flagger to control both AFADs through a single remote control.
Figure 3-5 Duo operation mode with one flagger
Before using the Duo Radio mode, the two AFAD units must be paired with the wireless remote
control (see 3.4 Pairing the AFAD Units
).
WARNING
Make sure there is nothing under the gate. If there is an object under the
gate, the gate will keep going down and might cause injuries or material
damage before stopping.
