VER-MAC V-Touch AFAD User Manual

V-Touch AFAD
MAN-13
User’s Manual
34 2.1
Figure 5-2 Connection identification
3 Check the motor (K-2900C) and switch (K-2904R) cables.
4 Close the front panel and push the V-Touch switch to the ON.
Once the blockage cause has been resolved, on the V-Touch AFAD screen, tap the Reset error
button.
IMPORTANT
When you tap Reset error, the gate closes completely and the red light
turns on. Make sure there is nothing under the gate before tapping the
button.
Power
Data
K-2900C
Switch
