Configuration Parameters D-3
Appendix D: Using the Configuration File
Edge 5000 Installation / Configuration Guide
LAN tftp_server_address Defines the IP address or URL of a TFTP provisioning server.
The valid value is an IP address or FQDN.
The default is blank
tos Sets Type of Service (ToS) value for SIP packets.
Valid values are 00 to FF (Hex).
Default is 0.
pc_802_priority Establishes the IEEE 802.1 priority for Ethernet frames at the PC
port of the IP Phone.
Valid values are 0 to 7.
Default is 3.
phone_802_priority Establishes the IEEE 802.1 priority for Ethernet frames at the
voice port, including signaling and voice packets, of the IP
Phone.
Valid values are 0 to 7.
Default is 5.
pc_vlan_id Assigns unique identifier of the VLAN for the PC port. A ‘0’
disables VLANS.
Valid values are 0 to 4094
Default is 0, disable.
phone_vlan_id Assigns unique identifier of the VLAN for the LAN (voice) port. A
‘0’ disables VLANS.
Valid values are 0 to 4094
Default is 0, disable.
NETTIME sntp_server_address Sets the IP address or FQDN of the SNTP server from which the
phone obtains time data.
Valid value is an IP address or FQDN.
Default is blank,
interval Sets interval, in hours, between time sync with SNTP server.
Valid values are 0 to 120 hours.
Default is 1.
timezone Sets the time zone for the phone.
Valid values are time zones shown on page
Default is 3, Pacific Standard time.
time_format Sets the LCD display format for time.
Valid values are 0 (off), 1 (12-hour) or 2 (24-hour).
Default is 2.
Section Field Name Description
