Configuration Parameters D-8
Appendix D: Using the Configuration File
Edge 5000 Installation / Configuration Guide
VOIP line1_proxy_address ~
linen_proxy_address
Each line requires the address of the SIP proxy server. The
linen_proxy_address and the linen_proxy_port parameters
assign the proxy address and port to each line. The value of "n"
can be from 1 to the max_line_num.
Valid value is an IP address or FQDN.
Default is blank.
line1_proxy_port ~
linen_proxy_port
Assigns the port number for the SIP proxy server. The n variable
is the line button and can be from 1 to the max_line_num.
Valid values are 1024 to 32000.
The default is 5060.
line1_displayname ~
linen_displayname
Specifies the caller identification for the line, the phone sends the
caller id for the line.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_name ~
linen_name
Defines the SIP user id that is often a number or SIP address for
use when registering. Enter a number without dashes, enter
555-0100 as 5550100, or a SIP address without the host name.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_authname ~
linen_authname
Specifies the name for authentication if the proxy server
challenges the line registration. It is required only if a proxy
server requires authentication.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_password ~
linen_password
Specifies the password for authentication if the proxy server
challenges the line registration.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
Section Field Name Description
