Configuration Parameters D-10
Appendix D: Using the Configuration File
Edge 5000 Installation / Configuration Guide
ROUTE add Defines a dial plan using a Routing Table. This parameter adds
entries to the table. If a dialed number matches an entry, the
number is modified and the call processed. An entry may
include 0 to 9, ‘*’ and ‘#’ and the following special characters.
‘~’ a wild card character that matches any multiple characters.
‘?’ any dialed digit.
‘.’ represents “virtual dial tone”
‘,’ locates the position of a 3-sec. pause in the prefix number.
Valid values are up to 50 entries with below information.
The default is blank.
intf --
Must be “SIP”.
port -- Must be “0”.
nums -- Sets the digit pattern for a match.
The valid value is a sequence of digits 0 to 9, ‘*’, ‘#’, ‘~’, ‘?’, ‘.’
or NULL.
trunc -- Specifies the number of digits to be stripped before
further processing.
Valid values are 0 to 31.
pre -- Specifies digits to add in front of the truncated number.
Valid values are 0 to 9, ‘*’, ‘#’, ‘.’, ‘~’ or NULL.
post -- Specifies the number to add at the back of the
truncated number.
Valid values are 0 to 9, ‘*’, ‘#’, ‘.’, ‘~’ or NULL.
pause -- Locates the position of a 3 seconds pause before
processing the number. A ‘,’ locates the pause in the entry.
Valid values are ‘?’, ‘,’ or NULL.
ip-addr -- Specifies an IP address as the destination when a
match occurs without regard to the proxy address.
The valid value is an IP address
DSP handsfree Specifies the gain level for the phone’s handsfree speaker.
Valid values are 1 through 11.
The default is 6.
handset Specifies the gain level for the phone’s handset.
Valid values are 1 through 11.
The default is 6.
Section Field Name Description
