Model GXT5 16KIRT9UXLN 16KIRT9UXLE 20KIRT9UXLN 20KIRT9UXLE
Rating 16000 VA/16000 W 20000 VA/20000 W
Dimensions, mm (in.)
Unit, W x D x H 430×630×394 (16.9×24.8×15.5)
Shipping, W x D x H 900×1200×700 (35.4×47.2×27.6)
Weight, kg (lb)
Unit 135.2 (298)
Shipping 190 (418.9) 186.7 (411.6) 190 (418.9) 186.7 (411.6)
Input AC Parameters
Operating Frequency, Nom. 50 or 60 Hz (factory default is 50 Hz)
Factory default VAC 230 VAC
User configurable VAC 200/208/220/230/240 VAC (Adjustable using operation/display configuration options)
Operating voltage range without battery
operation
176 – 288 VAC (100 – 176 VAC with power derating)
Maximum Allowable VAC 288 VAC
Input frequency without battery operation 40 – 70 Hz
Input Power Connection Input terminal block
Output AC Parameters
AC-AC Efficiency 95%
Factory default VAC Frequency 230 VAC, 50 Hz
Output Power Connection Output terminal block
Waveform Sine wave
Main Mode Overload > 150% minimum 200 ms; 125 – 150% for 60 seconds 105 – 125% for 5 minutes; ≤ 105% continuous
Internal Battery Charger
Charger Current, A 2.25 A default, maximum 13 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Quantity x Voltage x Rating 32 x 12 V x 9.0 AH
Back-up time See Table 8.20 on page104. See Table 8.21 on page105.
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable bypass operation When the input frequency prevents synchronous operation.
Environmental Parameters
Table 8.6 UPS Specifications, 16 kVA and 20 kVA Models
