Vertiv Liebert GXT5 User Manual

8 Specifications
Model GXT5 750IRT2UXL 750IRT2UXLE 1000IRT2UXL 1000IRT2UXLA 1000IRT2UXLE
Rating 750 VA/750 W 1000 VA/1000 W
Dimensions, D×W×H, in. (mm)
Unit 15.7 x 16.9 x 3.4 (400 x 430 x 85)
Shipping 24.3 x 22.4 x 10.3 (617 x 570 x 262)
Weight, lb. (kg)
Unit 36.3 (16.5)
Shipping 51.7 (23.5) 46.2 (21) 51.7 (23.5) 46.2 (21)
Input AC
Voltage (typical) 230 VAC nominal; variable based on output load
90% to 100% loading 168 to 288 VAC
70% to 90% loading 150 to 288 VAC
50% to 70% loading 115 to 288 VAC
0 to 50% loading 115 to 288 VAC
Frequency 40 Hz to 70 Hz; Auto Sensing
Input Power Cord C14
Output AC
Output Receptacles C13×8 IRAMx3 C13×8
Voltage 200/208/220/230/240 VAC (user configurable); ±3%
Waveform Sine wave
Utility (AC) Model Overload
>200% for 250 ms
150-200% for 2 seconds
125-150% for 50 seconds
105-125% 60 seconds
Internal Charger
Charging current Nominal 2.2 A; Maximum 8 A
Battery
Type Valve-regulated, non-spillable, lead acid
Qty×V×Rating 3 × 12 V × 9.0 Ah
Backup time See Battery Run Times on page99.
Recharge Time 3 Hours to 90% capacity after full discharge with 100% load until UPS auto-shutdown (Internal Batteries Only)
Table 8.1 UPS Specifications, 750 VA and 1000 VA Models
8 Specifications Proprietary and Confidential ©2024 Vertiv Group Corp. 85
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv Liebert GXT5 Specifications

General

Output Voltage	200/208/220/230/240 VAC
Topology	Double Conversion Online
Input Voltage	200/208/220/230/240 VAC
Output Frequency	50/60 Hz
Display	LCD
Operating Temperature	0 to 40°C (32 to 104°F)
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Power Capacity	1-20 kVA
Communication Ports	USB, RS-232
Waveform Type	Sinewave
Input Frequency	50/60 Hz
Power Factor	0.9
Operating Humidity	0-95% non-condensing
Battery Type	Valve-regulated lead acid (VRLA)
