Vertiv Liebert GXT5 User Manual

Extended Battery
Cabinet
Extended Battery Cabinet Notes Size (Capacity)
GXT5-EBC36VRT2U
02312369
6 PCS 9 AHbatteries ,36 V, one unit can use 10 cabinet in Max 50 A 1Pin
GXT5-EBC36VRT2UE
02312370
6 PCS 9 AHbatteries ,36 V, one unit can use 10 cabinet in Max 50 A 1Pin
GXT5-EBC48VRT2U
02312371
8 PCS 9 AHbatteries ,48 V,one unit can use 10 cabinet in Max 63 A 1Pin
GXT5-EBC48VRT2UE
02312372
8 PCS 9 AHbatteries ,48 V,one unit can use 10 cabinet in Max 63 A 1Pin
GXT5-EBC72VRT2U
02312373
12 PCS 9 AHbatteries ,72 V,one unit can use 10 cabinet in Max 63 A 1Pin
GXT5-EBC72VRT2UE
02312374
1 2PCS 9 AHbatteries ,72 V,one unit can use 10 cabinet in Max 63 A 1Pin
GXT5-EBC144VRT2U
02312367
12 PCS 9 AHbatteries ,144 V,one unit can use 10 cabinet in Max, Battery Cabinet shipping without internal
battery kit
63 A 2Pin
GXT5-EBC288VRT4U
02312368
24 PCS 9 AHbatteries 288 V,one unit can use 11 cabinet in Max, Battery Cabinet shipping without internal
battery kit
63 A 2Pin
GXT5-EBC192VRT3U
02312376
16 PCS 9 AHbatteries ,192 V,one unit can use 10 cabinet in Max, Battery Cabinet shipping with internal
battery kit
63 A 2Pin
GXT5-EBC384VRT3U
02312377
32 PCS 9 AHbatteries ,384 V,one unit can use 10 cabinet in Max, Battery Cabinet shipping with internal
battery kit
63 A 2Pin
Table 8.10 GXT5 EBC Breaker Sizes
8.1 Battery Run Times
NOTE: Run times in this table are approximate. Times are based on new, fully charged, standard battery modules at a
temperature of 77 °F (25 °C) with 100% resistive UPS loading. Run times listed above can vary by ±5% due to
manufacturing variances of the individual batteries.
Load
Internal
Battery
Only
Number of External Battery Cabinets
1 2 3 4 5 6 7 8 9 10
% VA W Minutes
10 75 75 135.4 444.1 770.8 1123.4 1452.2 1695.4 1863.8 1987.3 2081.7 2156.3 2216.6
20 150 150 68.0 229.0 401.4 581.6 760.5 952.0 1147.8 1330.7 1499.7 1635.5 1745.4
30 225 225 44.1 163.7 281.7 407.9 537.8 663.9 800.6 939.7 1080.9 1221.8 1350.2
40 300 300 33.7 127.1 218.3 316.1 416.5 519.9 620.3 724.8 833.9 944.6 1056.5
Table 8.11 Battery Run Time, 750 VA Models
8 Specifications Proprietary and Confidential ©2024 Vertiv Group Corp. 99
Vertiv™ Liebert® GXT5 UPS Installer/User Guide

Vertiv Liebert GXT5 Specifications

General

Output Voltage	200/208/220/230/240 VAC
Topology	Double Conversion Online
Input Voltage	200/208/220/230/240 VAC
Output Frequency	50/60 Hz
Display	LCD
Operating Temperature	0 to 40°C (32 to 104°F)
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Power Capacity	1-20 kVA
Communication Ports	USB, RS-232
Waveform Type	Sinewave
Input Frequency	50/60 Hz
Power Factor	0.9
Operating Humidity	0-95% non-condensing
Battery Type	Valve-regulated lead acid (VRLA)
