2.5 Internal Battery Packs
An example of the Vertiv™ Liebert® GXT5 internal battery packs is shown in Figure 2.16 below. They are located behind the
access door on the front of the UPS. 3 kVA and below units have 1 battery pack, 5 kVA and 10 kVA units have 2 battery packs,
and 16 kVA to 20 kVA units have 4 battery packs. The battery pack size varies based on:
Figure 2.16 Internal Battery Pack
Item Description
1 Handle
2 Connector
