Item Description
1
About screen tabs with Efficiency tab selected.
NOTE: The tab shown in the figure is an example and will change according to the model.
Product Information
Product Type
UPS model number.
Serial number
UPS serial number.
Time since startup
Elapsed time since start-up of the UPS.
Boot FW version
Version of MCU boot firmware on the monitor board.
Monitor FW version
Version of MCU application firmware on the monitor board.
DSP FW version
Version of DSP firmware on the UPS power module.
MAC address
Shows the MAC address of the RDU101 card. This is only shown when the RDU101 card is installed.
IPv4 address
Shows the IPv4 address of the RDU101 card. This is only shown when the RDU101 card is installed.
Subnet mask
Shows the subnet mask of the RDU101 card. This is only shown when the RDU101 card is installed.
Gateway address
Shows the gateway address of the RDU101 card. This is only shown when the RDU101 card is installed.
Efficiency Tab
Capacity
This shows the maximum capacity of your UPS model.
Cap. (%)
This shows the percentage of the maximum capacity your UPS is currently using.
Eff. (%)
This shows the efficiency the UPS is currently operating at based on the Cap. (%) value.
Battery Age
5 Operation and Display Panel Proprietary and Confidential ©2024 Vertiv Group Corp. 73
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
