2.4.1. Base Pallet Cut-out Location Dimension
The position and dimensions of air outlet on the top cover of downflow unit are shown in Figure 2-12 and in
Table 2-5 respectively.
Sym. Description Sym. Description
P Power cable entry D Drain pipe hole
H Water inlet for humidifier CI/CO Chilled water inlet and outlet
Figure 2-12 The Position of Air Outlet on Top Cover Upflow Unit
