Vertiv | Liebert PEX+Chilled Water | User Manual 58
iCOM Controller Operation
Parameters Default Setting Range Description
U232 HIREM 09 32.3 °C 1.0 - 99.0 °C High Remote Temperature 09
U232 LOREM 09 12.8 °C 1.0 - 99.0 °C Low Remote Temperature 09
U233 HIREM 10 32.3 °C 1.0 - 99.0 °C High Remote Temperature 10
U233 LOREM 10 12.8 °C 1.0 - 99.0 °C Low Remote Temperature 10
U235 STPR MSG 0 (Disabled)
0 = No
1 = Yes
Static Pressure Message Enable
U236 HI STAT 320 Pa 2 - 350 Pa High Static Pressure Alarm Border Pa
U237 LO STAT 0 Pa 0 - 348 Pa Low Static Pressure Alarm Border Pa
U238 STAT OFF 0 (No)
0 = No
1 = Yes
Stat Pres Msg Disable for Unit O
U239 STAT FAN 0 (No)
0 = No
1 = Yes
Stat Pres Msg Disable for Fan Events
U240 HI RANG 320 Pa 0 - 350 Pa SP Transducer High Range Pa
U241 LO RANG 0 Pa 0 - 348 Pa SP Transducer Low Range Pa
To browse through the menu, press the enter button to highlight the option, and use the up or down button to
scroll. Password is required for changing the setpoints. Then, enter the SET ALARMS menu, press the enter
button to highlight the option, use the up or down button to browse the submenu. Press the enter button to enter
the selected parameter. Use the up or down button to change the setpoints, and press the enter button to save
the change, or press the ESC button to quit the change.
4.5.6. Sensor Data
The data acquired can be monitored by the sensors through the SENSOR DATA menu. The values are read only;
no setting or change is allowed.
4.5.7. Display Setup
The DISPLAY SETUP menu is used to set the LCD display attributes. Password is not required for changing the
setpoints. The parameters are described in the Table 4-7.
