Vertiv | Liebert PEX+Chilled Water | User Manual 14
Installation
Figure 2-2 Obliquity of the System
2.1.2. Unpacking
Move the unit to the location nearest to the final installation site and unpack it. Follow the procedures below for
unpacking.
• Removal of Paper Packaging
Remove the packaging tape and carton at first, then remove the top cover followed by dismantling the unit on
the sealing plastic, finally, remove the Honey Comb Paper Board. For better understanding see Figure 2-3.
No. Description No. Description
1 Top Cover 3 Honey Comb Paper Board
2 Remove Top Cover 4 Remove sealing plastic film and Honey Comb Paper Board
Figure 2-3 Removal of Honey Comb Paper Board
