Vertiv | Liebert PEX+Chilled Water | User Manual 26
Installation
No. Description No. Description
1 2-Ø52 Knock-out hole 3 3-Ø110 Knock-out hole
2 6-Ø35 Knock-out hole
Figure 2-14 Knock-out Holes on Side Panel of the Downflow Unit (unit: mm)
The unit has knock-outs on the panels, ensure to mount sleeve to the cable holes to avoid cutting of the cables.
