3 APPENDICES
Appendix A: Serial Port Configuration for Appliance Integration
The serial port (ttyS1)on the RPC2™ Communications Module uses the following configuration settings:
• Bits per second:38400
• Data Bits:8
• Parity:None
• Stop Bits:1
• Flow Control:None
Appendix B: Input Power Cord Wiring Type
WIRING TYPE PERMISSIBLE VOLTAGE PHASE REFERENCE
1 Pole - 3 Wire (L1, N, PE) L1
2 Pole - 3 Wire (L1, L2, PE) L12
2 Pole - 4 Wire (L1, L2, N, PE) L1, L12
3 Pole - 4 Wire (L1, L2, L3, PE) L12, L23, L31
3 Pole - 5 Wire (L1, L2, L3, N, PE) L1, L2, L3, L12, L23, L31
Table 3.1 Input Power Cord Wiring Type
Vertiv | RPC2™ Communications Module Command Reference Guide | 45
