D
Technical Specifications
MXPro is a four-input video production switcher, mixer, frame synchronizer/TBC (Time
Base Corrector), Manual Color Corrector, and special effects generator.
Table 19: MXPro Technical Specifications
GENERAL
Power Supply
External in-line; 110VAC@60Hz/220VAC@50 Hz universal
CE/FCC/UL/CSA Approved
(Non-US/Canada versions meet local regulatory standards)
Dimensions
16.6” x 9.5” x 3”
422mm x 241mm x 76mm
Weight
4 lbs. (1.8 kg)
Ambient Temperature
32-104
°
F
0-40
°
C
Ambient Humidity
Less than 90%
INPUTS
Video
4 x S-video (Y/C): Y=1 Vp-p, C=0.30 Vp-p, 75-ohm,
4-pin mini-DIN connectors
4 x composite: 1.0 Vp-p 75-ohm, RCA connectors
Audio
8 x RCA connectors, 15 k ohms
GPI
Mini-jack
OUTPUTS
Video (PREVIEW & MAIN)
1.0 Vp-p, 75 ohm, PREVIEW=1x RCA; MAIN=2x
RCA Connectors 2x S-Video
(MAIN): Y=1.0 Vp-p, C=0.3 Vp-p; 75 ohm, 4-pin mini-DIN connector
Audio (L and R)
1 k ohms, RCA connectors
Headphone
Stereo jack, 8-100 ohms, mono signal
