77
Functions Route
R
OUTE
The Route function has the following, primary purposes:
• Configure MXPro to match your equipment.
• Re-direct signals coming from an input device to different or multiple MXPro
channels.
• Split the audio input on IN 3.
Configuring MXPro
MXPro ships from the factory with the following default options:
• Source Input 1’s video and stereo audio are assigned to channel A, with the video
signal routed through the S-Video connector.
• Source Input 2’s video and stereo audio are assigned to channel B, with the video
signal routed through the S-Video connector.
• Source Input 3’s video and stereo audio are assigned to channel C, with the video
signal routed through the S-Video connector.
The audio inputs for Input 3 have a special feature. You can split the audio to
two different channels. Then use the Route function to indicate which connector
(Left or Right) you used.
• Source Input 4’s video and stereo audio are assigned to channel D and the Back-
ground Music channel, with the video signal routed through the S-Video connec-
tor. The Background Music channel is permanently assigned to Audio Input 4
and cannot be changed. See Chapter 12,
Working with Audio
, for additional infor-
mation.
Unless you tell MXPro otherwise, it assumes your sources are connected exactly as
described above and shown in the following diagram.
