73
Functions Display
D
ISPLAY
To control what appears on the Preview monitor, use the
DISPLAY
function. Press
DIS-
PLAY
to cycle through the different display configurations. See samples of these config-
urations on the next page. The illustrations show the key combination you can use to
directly access any display configuration.
STANDARD
–
Provides most extensive display. Shows preview images of all active
input sources and a menu of up to 30 different transitions from which you can
choose.
TWO CHANNEL
–
Displays preview images only for the CURRENT and NEXT
sources. Preview images increase in size, but Transitions Menu shows only 20
transitions.
FULL
–
Divides preview screen into four sections. Each section shows a preview
image of the currently active input sources. The Transitions Menu is not available.
NEXT
–
Displays only a full-screen preview image of the NEXT source.
CURRENT
–
Displays only a full-screen preview image of the CURRENT source.
When you run a transition, the Preview screen shows a full-screen image, running at
full frame-rate — the same as the signal going through the output channel.
