Byte Bit 7...0
10 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.0
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.1
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.2
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.3
n Bit 7: 0 (fix)
11 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: ... input I+1.4
n Bit 1: 0 (fix)
n Bit 2: ... input I+1.5
n Bit 3: 0 (fix)
n Bit 4: ... input I+1.6
n Bit 5: 0 (fix)
n Bit 6: ... input I+1.7
n Bit 7: 0 (fix)
12 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: End of measurement channel 0
(End of integration time)
n Bit 7 ... 1: 0 (fix)
13 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: End of measurement channel 1
(End of integration time)
n Bit 7 ... 1: 0 (fix)
14 Diagnostic interrupt due to "process interrupt lost" at...
n Bit 0: End of measurement channel 2
(End of integration time)
n Bit 7 ... 1: 0 (fix)
15 reserved
The record set 1 contains the 4byte of the record set 0 and addition-
ally 12byte module specific diagnostic data. The diagnostic bytes
have the following assignment:
Diagnostic record set 1
at pulse width modula-
tion
VIPA System 300SDeployment I/O periphery
Diagnostic and interrupt > Diagnostic interrupt
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 146
