RN
(RUN)
ER
(ERR)
DE IF Meaning
○ ● ○ ● Waiting state for start command from CPU.
on: ● | off: ○ | blinking (2Hz): BB
Slave operation
RN
(RUN)
ER
(ERR)
DE IF Meaning
green red green red
○ ○ ○ ○ Slave has no project respectively PtP is active.
BB ○ ○ ○ Slave is without master.
BB* ○ BB* ○ * Alternate flashing at configuration faults.
● ○ ● ○ Slave exchanges data between master.
on: ● | off: ○ | blinking (2Hz): BB
4.3 Technical data
Please consider with the configuration with the Siemens
TIA Portal the number of timer and counters is limited to
the maximum possible number of the corresponding Sie-
mens CPU.
Order no. 313-6CF13
Type CPU 313SC/DPM
SPEED-Bus -
Technical data power supply
Power supply (rated value) DC 24 V
Power supply (permitted range) DC 20.4...28.8 V
Reverse polarity protection
ü
Current consumption (no-load operation) 200 mA
Current consumption (rated value) 900 mA
Inrush current 11 A
I²t 0.7 A²s
Max. current drain at backplane bus 3 A
Power loss 14 W
VIPA System 300S Hardware description
Technical data
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 35
