6.2 In-/Output area CPU 313-6CF13
The CPU 313-6CF13 has the following digital in- and output ranges
integrated in one casing:
n Digital Input: 16xDC 24V, with interrupt capability
n Digital Output: 16xDC 24V, 0.5A
n Technological functions: 3 channels
X11:
CAUTION!
Please regard that the voltage at an output channel is
always £ the supply voltage connected to L+.
Overview
VIPA System 300S Deployment I/O periphery
In-/Output area CPU 313-6CF13
HB140 | CPU-SC | 313-6CF13 | GB | 15-50 97
